Truss Stage 17x14m

This is a proven, high-quality stage solution that has already established its presence on the Estonian market, designed to meet the needs of professional events.

What makes this stage stand out is its smart and durable design – the sides and back wall are covered with robust PVC material, providing significantly improved protection against rain and wind. This ensures a safe and stable environment for both performers and technical equipment, even in challenging weather conditions.

The stage comes standard with side areas on both sides, which can be configured either in full length or half-length, offering flexibility for both smaller and larger productions.

Additionally, the stage is equipped with integrated PA wings for sound and lighting systems, with a load capacity of up to 2 tons. Optional front extensions can be installed on the front towers, allowing up to 1 ton of additional PA equipment to be mounted.

For enhanced safety and control, a weather station is always included, enabling real-time monitoring of wind speed, precipitation, humidity, and other key conditions during the event.

With a 10-meter trim height (measured from the stage floor), the structure provides excellent space and is perfectly suited for large-scale productions.

Technical data

Internal width	16,88 m
Internal depth	14,5 m
Eave height	10,17 m
Ridge height	14,65 m
Side area size	10,35x5,14 m
Stage UDL	13200 kg
Stage PL (point load)	19100 kg

Truss Stage 17x14m with extended PA towers

We have taken our stage solution to the next level – introducing the extended PA tower solution, designed for larger and more technically demanding productions.

The extended PA tower means that the PA structure is integrated deeper into the stage construction, creating a double tower setup. This allows for the use of pre-rig systems and ensures more efficient load distribution across the structure.

As a result, the system offers significantly increased load capacity and flexibility, enabling larger and more complex rigging solutions for both PA systems and LED screens. This makes it an ideal choice for large-scale concerts, TV productions, and festivals where technical requirements are higher.

The extended PA tower solution provides production teams with greater freedom, enhanced safety, and the confidence to execute even the most demanding setups.

Technical data

Internal width	16,88 m
Internal depth	14,5 m
Eave height	10,17 m
Ridge height	14,65 m
Side area size	10,35x5,14 m
Stage UDL	13200 kg
Stage PL (point load)	19100 kg
